MB Series Plastic with LED 24V AC/DC White 22 mm Pilot

MB Series Plastic with LED 24V AC/DC White 22 mm Pilot

Product Code
MBSD024B
Certificate
CE UKCA
Downloads
  • Non-flammable V0 PA6.6 contact blocks
  • Monoblock strong body
  • Finger safe protection
MB Series Plastic with LED 24V AC/DC White 22 mm Pilot
Bulb Type
Led
Operating Current
13 mA
Operational Frequency
50 Hz
Operational Voltage
24V AC/DC
Product
Pilot
Color
White
Illumination
with LED
Dia
22 mm
Power Consumption
0.4W
Insulation Voltage (Ui)
250 V
Operating Temperature
-15 / + 70 °C
Protection Degree
IP50
Cable Section
1.5-2.5 mm²
Screw Torque
1,5 Nm
Production Time
31.12.1899 00:00:00
Serial
MB Series Plastic
Electrical Life (Min Hour)
10000
