Product Details



Plastic Retro Reflection Relay Output 7m with LED M12*4 Connector 50 mm Square Photoelectric Sensor Plastic Retro Reflection Relay Output 7m with LED M12*4 Connector 50 mm Square Photoelectric Sensor Plastic Retro Reflection Relay Output 7m with LED M12*4 Connector 50 mm Square Photoelectric Sensor

Plastic Retro Reflection Relay Output 7m with LED M12*4 Connector 50 mm Square Photoelectric Sensor

Product Code
SPQ50RP2CSX
Certificate
CE EAC SEPRO UKCA
Downloads
  • Fast switching
  • Resistant to friction and attrition
  • Short circuit and overload protection
  • Reverse polarity protection
Plastic Retro Reflection Relay Output 7m with LED M12*4 Connector 50 mm Square Photoelectric Sensor
Plastic Retro Reflection Relay Output 7m with LED M12*4 Connector 50 mm Square Photoelectric Sensor
Plastic Retro Reflection Relay Output 7m with LED M12*4 Connector 50 mm Square Photoelectric Sensor
Product
Square Photoelectric Sensor
Serial
SPQ Series Square Photoelectric Sensor
Body Material
Plastic
Type
Retro Reflection
Output/Contact Type
Relay Output
Sensing Distance
7m
Feature
with LED
Connection Type
M12*4 Connector
Connection / Nominal Dimension
50 mm
Operational Voltage
24-240 V AC/DC
Operational Frequency
50/60 Hz
Current (Ie)
250VAC 3A (rezistif)
Insulation Voltage (Ui)
1500 VAC
Impulse Withstand Voltage (Uimp)
75V DC
Operating Temperature
-20°C...+65°C
Pollution Degree
3
Protection Degree
IP50
Hysterisis
<%15 Sr (effective operating distance)
Number of Contact
1
Repeat Accuracy
<0,1 Sr
Switching Frequency
100 ms (Response Time)
Temperature Drift
<0,1 Sr
Time Delay Before Availability
≤100 ms
Ripple (Voltage)
< %10
EMC
61000-4-3 3V/m -- 61000-4-6 3
Sensing Face
PC
