Product Details
(3P+E)+2*(2P+E) Group Socket 1x(3x25A)+2x(1x16A) Kauçuk Fiş Priz
Product Code
EKS325PG12
Standard
TS IEC 60884-1-A1+A2
Certificate
Downloads
Operating Current
1x(3x25A)+2x(1x16A)
Product
Kauçuk Fiş Priz
Type
Group Socket
Contact
(3P+E)+2*(2P+E)
Usage Category
AC15
Mechanical Life (Min Qty)
≥ 5.000
Electrical Life (Min Qty)
≥ 1.000
Operating Frequency (On-Off/Hour)
Mech.240 Elec.120
Insulation Voltage (Ui)
690V
Impulse Withstand Voltage (Uimp)
2 kV
Dielectric Strength (Body-Contact)
1890V AC
Dielectric Strength (Contact-Contact)
2000V AC
Isolation Resistance
10 MΩ MİN. (500 V DC)
Operating Temperature
-40 / +80 °C
Pollution Degree
2
Protection Degree
IP44
Number of Cable and Cable Section
3*1,5 mm2
Production Time
31.12.1899 00:00:00
Serial
EKS Series
