Product Details



IK Series Single Level 24V AC/DC With Buzzer 100mm Tube Plastic Base LED Tower 50mm

IK Series Single Level 24V AC/DC With Buzzer 100mm Tube Plastic Base LED Tower 50mm

Product Code
IK50X024ZM03
Certificate
CE UKCA
Downloads
  • Heat resistant, clear vision Polycarbonate signal modules
  • Modular construction
  • Easy wiring
  • Variety of connection bases
IK Series Single Level 24V AC/DC With Buzzer 100mm Tube Plastic Base LED Tower 50mm
Weight (Gross with Carton) (Gr)
169
Operational Frequency
50 Hz
Operational Voltage
24V AC/DC
Product
LED Tower 50mm
Mounting
100mm Tube Plastic Base
Color
Single Level
Volume
90 dB
Power Consumption
1W
Operating Frequency (On-Off/Hour)
1 Hz
Insulation Voltage (Ui)
300V
Operating Temperature
-25 °C /+70 °C
Protection Degree
IP40
Cable Section
0,75-1,5 mm2
Screw Torque
1,8Nm
Production Time
31.12.1899 00:00:00
Serial
IK Series
Buzzer
With Buzzer
Electrical Life (Min Hour)
10000
