IK Series Single Level 24V AC/DC 45mm Tube Plastic Base with Etange LED Tower 50mm

Product Code
IK51L024XM02E
Certificate
CE UKCA
Downloads
  • Heat resistant, clear vision Polycarbonate signal modules
  • Modular construction
  • Easy wiring
  • Variety of connection bases
Weight (Gross with Carton) (Gr)
175
Bulb Type
LED
Operational Frequency
50 Hz
Operational Voltage
24V AC/DC
Product
LED Tower 50mm
Mounting
45mm Tube Plastic Base with Etange
Color
Single Level
Power Consumption
1W
Insulation Voltage (Ui)
300V
Operating Temperature
-25 °C /+70 °C
Protection Degree
IP65
Cable Section
0,75-1,5 mm2
Screw Torque
1,8Nm
Lampholder Type
BA15S
Production Time
31.12.1899 00:00:00
Serial
IK Series
Electrical Life (Min Hour)
10000
