IK Series Three Level 220V AC Flasher 110mm Plastic Tube and Base LED Tower 70mm

Product Code
IK73F220XM01
Certificate
CE UKCA
Downloads
  • Heat resistant, clear vision Polycarbonate signal modules
  • Modular construction
  • Easy wiring
  • Variety of connection bases
Weight (Gross with Carton) (Gr)
342
Bulb Type
LED
Operational Frequency
50 Hz
Operational Voltage
220V AC
Product
LED Tower 70mm
Mounting
110mm Plastic Tube and Base
Color
Three Level
Illumination
Flasher
Power Consumption
3W
Operating Frequency (On-Off/Hour)
1 Hz
Insulation Voltage (Ui)
300V
Operating Temperature
-25 °C /+70 °C
Protection Degree
IP40
Cable Section
0,75-1,5 mm2
Screw Torque
1,8Nm
Lampholder Type
BA15S
Production Time
31.12.1899 00:00:00
Serial
IK Series
Electrical Life (Min Hour)
10000
