Product Details
HJ Series 25A 220-230V/50-60HZ with Start and Reset Button 13,50-20,00A Contactor with Thermic in Box
Product Code
HJ22X25UP
Certificate
Downloads
Operational Frequency
50 - 60Hz
Product
Contactor with Thermic in Box
Current (Ie)
25A
Thermic Current Calibration Interval
13,50-20,00A
Usage Category
AC 3
Mechanical Life (Min Qty)
100000
Electrical Life (Min Qty)
100000
Operating Frequency (On-Off/Hour)
Mech. 600 Elec. 600
Insulation Voltage (Ui)
690V AC
Impulse Withstand Voltage (Uimp)
6 kV
Dielectric Strength (Body-Contact)
1890V AC
Dielectric Strength (Contact-Contact)
1890V AC
Isolation Resistance
10 MΩ (500 V DC)
Operating Temperature
-15 / +80 °C
Pollution Degree
3
Protection Degree
IP65
Cable Section
2,5 mm²
Screw Torque
1,8 Nm
Short Circuit Breaking Capacity (Ics)
50 kA
Serial
HJ Series
Voltage
220-230V/50-60HZ
Enclosure
with Start and Reset Button
