Product Details



RE1 Series 110VDC 3 Contact 11 Pin Industrial Relay RE1 Series 110VDC 3 Contact 11 Pin Industrial Relay RE1 Series 110VDC 3 Contact 11 Pin Industrial Relay

RE1 Series 110VDC 3 Contact 11 Pin Industrial Relay

Product Code
RE1P11DC110
Standard
TS EN 61810-1
Certificate
CE EAC SEPRO TSE UKCA
Downloads
  • V0 PA 6.6 material
  • DIN 35mm rail mountable with 8 and 11 pin socket
  • Body design and connection ends for quick and error-free assembly
  • Test button and indicator
  • Large labelling area for code writing
RE1 Series 110VDC 3 Contact 11 Pin Industrial Relay
RE1 Series 110VDC 3 Contact 11 Pin Industrial Relay
RE1 Series 110VDC 3 Contact 11 Pin Industrial Relay
Product
Industrial Relay
Serial
RE1 Series
Operational Voltage
110VDC
Contact
3 Contact
Pin
11 Pin
Current (Ie)
10 A (250V AC)
Usage Category
AC 15
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
100000
Operating Frequency (On-Off/Hour)
Mech. 18.000 Elec. 600
Insulation Voltage (Ui)
300 V
Impulse Withstand Voltage (Uimp)
1,5kV
Dielectric Strength (Body-Contact)
2.500V AC
Dielectric Strength (Contact-Contact)
1.500V AC
Isolation Resistance
MIN. 10 MΩ (500 V DC)
Operating Temperature
-15 / +80 °C
Pollution Degree
3
Protection Degree
IP40
Contact Material
AgNi
