  5. RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter

Product Details



RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter

RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter

Product Code
RDA1A
Certificate
CE UKCA
Downloads
  • Compact design
  • Fast and silent switching
  • Long life
  • Fingerproof design
RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter
RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter
RD Series 8 Pins 230VAC 1CO 5A (rezistif) Digital Ampermeter Panelmeter
Current Transformer Setting
…/5 A
Switching Capacity
6000/saat
Connection Type
8 Pins
Operational Frequency
50Hz
Operational Voltage
230VAC
Product
Panelmeter
Control
Digital
Type
Ampermeter
Contact
1CO
Current (Ie)
5A (rezistif)
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
100000
Operating Temperature
-5°C...+55°C
Protection Degree
IP20
Contact Material
AgNi
Output Type
1 pcs relay 10A/250V AC
Measure Interval
0…5 A
Maximum Contact Power
1500 VA
Number of Contact
1 changeover
Voltage Interval
(0,85-1.1)*Ue
Indicator
7 Segment Display
Number of Digits
3
Serial
RD Series
