Product Details
RZ1 Series 8 Pins 230VAC 1CO+1NO 5A (rezistif) 1sec-30min Analog Time Electronic Relay
Product Code
RZ1A2C30M-5
Certificate
Downloads
Switching Capacity
6000/saat
Connection Type
8 Pins
Operating Current
0.065A
Operational Frequency
50 Hz
Operational Voltage
230VAC
Product
Electronic Relay
Control
Analog
Type
Time
Contact
1CO+1NO
Current (Ie)
5A (rezistif)
Power Consumption
<13VA
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
100000
Operating Temperature
-5°C...+55°C
Protection Degree
IP30
Contact Material
AgNi
Time Interval
1sec-30min
Maximum Contact Power
150 W, 1,250 VA
Number of Contact
1NO,1 changeover
Repeat Accuracy
±%3
Max. Reset Time
≤100ms
Voltage Interval
(0,85-1.1)*Ue
Indicator
Led
Serial
RZ1 Series
