Product Details



RZ4 Series 8 Pins 24-240VAC/DC 1CO 3A (rezistif)@250V AC 0.05sec-10sa Analog Time Electronic Relay

Product Code
RZ4A2M00A7P
Certificate
CE UKCA
Downloads
  • Compact design
  • Fast and silent switching
  • Long life
  • Fingerproof design
Switching Capacity
6000/saat
Connection Type
8 Pins
Operational Frequency
50 Hz
Operational Voltage
24-240VAC/DC
Product
Electronic Relay
Control
Analog
Type
Time
Contact
1CO
Current (Ie)
3A (rezistif)@250V AC
Power Consumption
<5VA
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
100000
Operating Temperature
-5°C...+55°C
Protection Degree
IP30
Contact Material
AgNi
Time Interval
0.05sec-10sa
Maximum Contact Power
150 W, 1,250 VA
Number of Contact
2 changeover
Repeat Accuracy
±%3
Max. Reset Time
≤100ms
Serial
RZ4 Series
