Product Details
RZ4 Series With terminal 24VAC/DC 1CO 5A (rezistif) Digital Counter Electronic Relay
Product Code
RZ4D1C208K
Certificate
Downloads
Switching Capacity
6000/saat
Connection Type
With terminal
Operating Current
0.035A
Operational Frequency
50 Hz
Operational Voltage
24VAC/DC
Product
Electronic Relay
Control
Digital
Type
Counter
Contact
1CO
Current (Ie)
5A (rezistif)
Power Consumption
0.7W
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
100000
Operating Temperature
-5°C...+55°C
Protection Degree
IP30
Contact Material
AgNi
Maximum Contact Power
1500 VA
Number of Contact
1 changeover
Max. Reset Time
≤100ms
Voltage Interval
(0,85-1.1)*Ue
Indicator
7 Segment Display
Number of Digits
4
Serial
RZ4 Series
