Product Details
RZ4 Series 8 Pins 12VAC/DC 1CO 5A (rezistif) 0,1sec-99,59hour Digital Time Electronic Relay
Product Code
RZ4D1R108P
Certificate
Downloads
Serial
RZ4 Series
Number of Digits
4
Indicator
7 Segment Display
Voltage Interval
(0,85-1.1)*Ue
Max. Reset Time
≤100ms
Number of Contact
1 changeover
Maximum Contact Power
1500 VA
Time Interval
0,1sec-99,59hour
Contact Material
AgNi
Protection Degree
IP30
Operating Temperature
-5°C...+55°C
Electrical Life (Min Qty)
100000
Mechanical Life (Min Qty)
10000000
Power Consumption
0.4W
Current (Ie)
5A (rezistif)
Contact
1CO
Type
Time
Control
Digital
Product
Electronic Relay
Operational Voltage
12VAC/DC
Operational Frequency
50 Hz
Operating Current
0.04A
Connection Type
8 Pins
Switching Capacity
6000/saat
